Air Oil Separator Filter 1604038201 2911007500 2911011200
Product Overview
This air-oil separator element is designed for screw compressor maintenance replacement. Utilizing a fine fiberglass coalescing layer, it effectively captures oil mist particles from compressed air, reducing oil carryover and protecting downstream equipment. Suitable for compressed air systems in manufacturing, electronics, metallurgy, and chemical industries.
Specifications
| Parameter | Specification |
|---|---|
| Part Number | 1604038201 / 2911007500 / 2911011200 |
| Media | Ultra-fine fiberglass |
| Working Medium | Compressed air & lubricant mixture |
| Separation Type | Coalescing air-oil separation |
| Construction | Multi-layer composite media, sealed end caps |
| Replacement Indication | Inspect/replace when pressure drop rises or oil carryover increases |
| Reference Service Life | Depends on operating conditions; shorten inspection intervals in dusty, high-temperature, or high-load environments |
Note: Dimensional data may vary reasonably by batch and measurement method; actual product shall prevail.
Product Details
1. Coalescing Separation Principle
Oil mist carried by compressed air is intercepted by the ultra-fine fiber layer; micro-droplets coalesce into larger droplets, settle at the element bottom, and return to the lubrication system via the oil return line. This structure helps maintain low oil carryover and reduce lubricant consumption.
2. Media & Construction
The element features a multi-layer composite construction: pre-filter layer, ultra-fine fiber coalescing layer, and support layer, balancing contaminant holding capacity and flow resistance. End caps and seals fit tightly to minimize bypass leakage risk.
3. Application & Replacement Guidance
Replace the separator when the pressure differential rises, or when increased oil carryover or oil consumption is observed. In dusty, high-temperature, or continuous high-load conditions, inspection intervals should be shortened accordingly.
4. Quality Control
Production control covers media weight, pleating consistency, end-cap bond strength, and finished-product seal integrity, ensuring structural integrity under rated pressure differential and reducing fiber migration risk.
