AE120XL & AE120L Precision Filter Elements – Efficient Oil-Water Separation & Particle Filtration
Product Overview
The AE120XL and AE120L precision filter elements are engineered for compressed air systems to effectively remove oil mist, water vapor, and solid particulates. Both models are manufactured with premium filtration media to ensure clean, dry compressed air for downstream equipment, suitable for a wide range of industrial applications with demanding air quality standards.
| Model | Filtration Grade | Residual Oil Control | Recommended Use |
|---|---|---|---|
| AE120XL | Fine filtration grade | Reduced to trace levels | Pre-filtration / Primary stage |
| AE120L | Fine filtration grade | Reduced to trace levels | Pre-filtration / Primary stage |
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AE120XL / AE120L |
| Filter Media | High-performance composite fibers + filter felt |
| Filtration Grade | Fine grade (effectively captures micro-sized oil mist and particulates) |
| Residual Oil Control | Maintained at very low levels to meet precision air requirements |
| Particle Removal Capability | High removal efficiency with consistent performance |
| Temperature Resistance | Suitable for normal to conventional industrial high-temperature conditions |
| Max. Operating Differential Pressure | Recommended to maintain within reasonable range to avoid overloading |
| Seal Material | Premium NBR / FKM (optional based on requirements) |
| Service Life | Durable and long-lasting; actual life depends on operating conditions |
| Filtration Type | Coalescing filter media |
| Suitable Medium | Compressed air |
Product Details
Working Principle
The AE120XL / AE120L precision filter elements utilize proven coalescing filtration technology. As compressed air passes through the filter element, the dense microfibers within the filter media work in synergy to:
Capture solid particulates – effectively removes both visible and micro-sized solid contaminants from compressed air
Coalesce oil and water aerosols – causes fine oil mist and water vapor droplets to merge into larger droplets on fiber surfaces for easier separation
Enable automatic drainage – coalesced oil-water mixture settles at the bottom and can be automatically discharged through the oil return system
Key Advantages
Stable high-efficiency filtration – premium composite fiber media ensures consistent filtration performance with gradual pressure drop increase
Extended service life – carefully selected materials and robust design effectively reduce replacement frequency and maintenance costs
Excellent sealing performance – equipped with high-quality seals to ensure leak-proof installation
Broad compatibility – widely compatible with various air compressors and compressed air piping systems
Reliable output quality – ensures stable compressed air quality to meet the standards of precision equipment and critical processes
Application Areas
Pre-filtration for air compressor after-treatment systems
Inlet filtration protection for refrigerated dryers
Pre-protection filtration for adsorption dryers
Compressed air purification for precision instruments, electronics manufacturing, and food & beverage industries
High-quality air supply for spraying, pharmaceutical, chemical, and other industries with stringent air quality requirements
Packaging & Shipping
Packaging: Sealed plastic liner inside + export-standard carton; wooden cases or pallets available for large/heavy items
Shipping Methods: Express, air freight, sea freight, China-Europe Railway Express (door-to-door service available)
Delivery Time: Fast delivery for regular products; customized orders delivered per agreed schedule
Quality & Services
Quality assurance provided after shipment
Professional and timely pre-sales consultation and after-sales technical support
XINXIANG MENGMA FILTER CO.,LTD.
📞 Tel: +86 150 9033 8589
📧 Email: joy@mmfilter.com
Welcome to send drawings or samples for inquiry. We look forward to establishing a long-term and stable partnership with you!
