1613901400 Air Compressor Oil Separator
High-Efficiency Coalescing Element for Screw Compressor Oil Separation
Product Parameters
| Parameter | Details |
|---|---|
| Model | 1613901400 |
| Media Type | Ultrafine glass fiber composite |
| Filtration Grade | Precision grade |
| Separation Effect | High-efficiency coalescing |
| Oil Carryover | Low carryover design |
| Pressure Drop | Low-resistance construction |
| Service Interval | Extended-life type |
| Temperature Range | Wide operating range |
| Seal Options | Fluororubber / Nitrile rubber (optional) |
| Mounting | Vertical flange installation |
Product Details
Overview
This oil separator cartridge is developed for the air-oil separation stage of oil-injected screw compressors. Installed between the compression unit and the downstream air network, it captures oil mist and helps maintain clean air delivery. As a directly replaceable filter element, it reduces the risk of oil reaching pneumatic tools, production equipment, and end products.
How It Works
The air-oil mixture discharged from the compressor first undergoes coarse separation inside the receiver tank, where larger droplets settle under gravity. The remaining fine mist enters the filter media, where multiple layers of ultrafine glass fiber intercept and coalesce the droplets into larger ones. The coalesced oil gathers at the bottom of the cartridge and returns to the lubrication circuit through the oil return line, forming a closed loop.
Construction Breakdown
| Component | Description |
|---|---|
| Filtration Layer | Multi-layer ultrafine glass fiber composite; strong retention with low airflow resistance |
| Inner Core | Perforated metal, corrosion-resistant; pleats hold shape under pressure cycling |
| End Caps | High-strength bonding keeps sealing surfaces intact at elevated temperatures |
| Seal Ring | Precision-fit elastomer prevents unfiltered air from bypassing |
Operational Benefits
Clean air output: The coalescing layer limits oil mist penetration, reducing contamination load on downstream dryers and precision pneumatic components.
Energy-friendly: Pleat layout and optimized media surface keep airflow resistance low, helping cut extra power consumption caused by pressure differential.
Long replacement cycle: Under normal conditions and proper oil maintenance, the cartridge works steadily and reduces shutdown frequency for part changes.
Flexible fit: Available for compressor units with matching flange mounting and connection dimensions.
Application Scope
Used in oil-injected screw compressors across general manufacturing, textile, electronics assembly, pharmaceutical processing, and pneumatic conveying applications.
Quality Control
Every production batch undergoes burst verification, structural integrity inspection, end-load testing, and differential pressure flow characterization before shipment.
Contact Information
Company: XINXIANG MENGMA FILTER CO., LTD.
Phone: +86 150 9033 8589
Email: joy@mmfilter.com
For technical specifications or custom requirements, please contact us directly. Business inquiries receive a reply within 24 hours.
