Air Oil Separator Element 1613243300 2901007800 for Screw Air Compressor High-Efficiency Oil Removal
Product Specifications
| Item | Parameter |
|---|---|
| Model | 1613243300 / 2901007800 |
| Product Type | Oil-Gas Separation Filter Element |
| Compatible Machines | Oil-Injected Screw Air Compressors |
| Media Construction | Borosilicate glass microfiber composite, with coalescing, separation and drainage layers |
| Interception Capability | Effectively coalesces submicron oil mist aerosols |
| Separation Performance | Low residual oil content in discharged compressed air |
| Resistance Characteristics | Low initial resistance, gradual differential pressure rise |
| Replacement Timing | When differential reaches machine-specified value or service hours expire |
| Temperature Range | Suited to normal compressor discharge temperature conditions |
| Service Cycle | Long-cycle design, actual duration depends on site conditions |
| Sealing Component | Oil-resistant synthetic rubber seal ring |
| Dimensions | Manufactured to corresponding machine interface dimensions |
| Weight | Lightweight metal end cap construction |
Product Details
Working Principle
In the oil-gas separation system of an oil-injected screw compressor, this element occupies the final fine separation stage. The oil-gas mixture discharged from the compression chamber first loses most liquid oil through cyclone and gravity action inside the tank. The remaining fine oil mist suspended in the airflow then enters the filter element. As the mist passes through the glass fiber layers, it is captured on fiber surfaces and gradually gathers into droplets. These droplets slide down the fibers to the bottom of the element and are returned to the main lubrication circuit through the oil return line. Through this process, the oil content in the discharged air is kept at a low level.
Materials and Craftsmanship
The element uses borosilicate glass microfiber as the primary filtration medium, offering fine fiber diameter and large specific surface area for stable oil mist coalescence. The media is laid in three functional layers-coalescing, separation and drainage-each handling a distinct task to prevent premature saturation of a single structure. End caps and center骨架 are formed by stamping, and bonding uses a high-temperature and oil-resistant adhesive formula that resists cracking or detachment under temperature fluctuations or oil attack. The seal ring is separately molded for a tight fit after assembly.
Operating Advantages
Low differential pressure means reduced compressor back pressure, contributing to relative energy savings over long-term operation. High coalescing efficiency reduces lubricant loss with the airflow, extending oil top-up intervals while easing the oil contamination burden on downstream refrigerated dryers, precision filters and air-using equipment. Structural strength is sufficient to resist deformation under pulsating airflow and alternating temperature conditions, preventing poor oil return or separation failure caused by element collapse.
Assembly and Maintenance
After shutdown and depressurization, open the separation tank cover, remove the old element and clean accumulated oil and debris inside the tank. Before seating the new element, confirm the sealing surface is clean and the seal ring is undamaged. Align with the locating structure during installation, apply even pressure to compress, and avoid tilting. Tighten bolts alternately in a diagonal pattern. After startup, first observe the differential pressure gauge reading and the seal condition, and confirm no abnormality before putting into normal operation. During subsequent inspections, watch the trend of differential pressure changes and arrange replacement as it approaches the threshold. Replacing lubricating oil and oil filter at the same time helps maintain system cleanliness.
