Air Oil Separator 1613750201 High-Efficiency Coalescing Element
Product Overview
During screw compressor operation, lubricant inevitably mixes with compressed air as it discharges. If oil-air separation is incomplete, oil mist travels into downstream piping, contaminating air-operated equipment and increasing oil consumption. The 1613750201 separator element is designed for this exact stage, installed inside the oil reservoir to handle the final separation between compressed air and lubricant.
Key Specifications
Filtration Rating: Micron-level interception
Residual Oil Control: Low residual oil level
Separation Efficiency: High-efficiency coalescing
Initial Pressure Drop: Low pressure loss
Total Height: Fits standard models
Outer / Inner Diameter: Fits standard models
Net Weight: Lightweight
Media: Glass fiber coalescing material
Application: Compressed air and lubricant mixture
Operating Temperature: Compatible with standard screw compressor discharge temperatures
Product Details
Q: How does this element work?
The oil-air mixture first exits the airend into the oil reservoir, where larger droplets settle naturally by gravity and centrifugal force. The remaining fine mist follows the airflow through the element, gets intercepted inside the glass fiber layer, merges into larger droplets, sinks to the element base, and returns to the lubrication system via the scavenge line. Clean air exits through the element center.
Q: What is the internal construction?
Multi-layer composite media. The outer layer captures large droplets and guides flow; the middle layer merges micron-sized mist into separable droplets; the inner core maintains structural integrity against pressure fluctuations. End caps and seals work together so the oil-air mixture must pass through the media with no bypass leakage.
Q: What benefits does it offer?
Stable outlet oil content reduces carbon buildup and oil contamination downstream; low pressure drop helps cut energy consumption and maintain discharge volume; glass fiber resists high temperature and oil corrosion for prolonged continuous operation; a balanced dust-holding structure allows gradual pressure rise, reducing unexpected downtime.
Q: Where is it used?
In the oil-air separation stage of screw air compressors. Suitable for compressed air stations in manufacturing, mining, textile, and chemical industries. Timely replacement helps maintain air quality and extends the life of dryers, filters, and pneumatic tools.
Q: When should it be replaced?
When pressure differential reaches the specified value, or operating duration reaches design life. Confirm the system is depressurized before operation to avoid hot oil spray.
Contact Information
Company: XINXIANG MENGMA FILTER CO., LTD.
Contact: Joy
Phone/WhatsApp: +86 150 9033 8589
Email: joy@mmfilter.com
Inquiries for quotation, samples, and selection support are welcome.
