1092081600 Screw Air Compressor Oil Separator Element Low Oil Carryover High Efficiency Oil Separation Filter
Specifications
| Parameter | Specification |
|---|---|
| Model | 1092081600 |
| Type | Oil Separator Element |
| Separation Method | Coalescing |
| Oil Carryover | Low |
| Differential Pressure | Stable |
| Service Duration | Long |
| Media | Composite Fiberglass |
| Seals | FKM / NBR |
| Compatible Oils | Mineral Oil, Synthetic Oil |
| Temperature | Stable at high temperature |
| Packing | Neutral / Customized |
Check These Before Replacement
Which machine it fits
The 1092081600 goes into the oil separation housing of screw air compressors. Before installation, verify housing dimensions, port positions, and oil return line routing. Wrong dimensions will not fit, and a misrouted return line directly affects separation performance.
What to look for on the old element
After removal, first check whether the bottom oil return hole is blocked, then inspect the media for damage, deformation, or moisture. Excessive oil accumulation at the base usually indicates poor oil return, which should be addressed together with the replacement.
When to replace
Watch the differential pressure gauge. When the reading rises noticeably above a freshly installed element, or operating hours approach the maintenance manual's recommended value, schedule a replacement. Waiting until oil carryover is visible means oil has already entered downstream piping.
What Improves After Installation
Oil carryover in exhaust drops, reducing the load on downstream dryers and filters. Differential pressure falls back, so the compressor does not work extra and power consumption follows. Oil return runs smoothly, lubricant is not carried away, and oil consumption returns to normal.
Industries Served
Metallurgy, electronics, pharmaceuticals, textiles, petrochemicals, and power generation - wherever clean compressed air is required.
Packaging & Shipping
| Item | Description |
|---|---|
| Packing | Carton, customizable |
| MOQ | Negotiable |
| Port | Shanghai / Ningbo / Qingdao |
| Lead Time | Several working days after order confirmation |
