Air Compressor Oil Separator Element 02250106-789
Product Description
Product Overview
This oil separator element (Part No.: 02250106-789) is purpose-built for oil-injected rotary screw compressors, playing a vital role in the fine separation of oil from compressed air. It effectively captures suspended lubricating oil and returns it to the circulation system, ensuring delivery of clean air and extending the service life of downstream equipment. Manufactured with premium composite fiber media and advanced winding/pleating techniques, this element achieves an excellent balance between separation efficiency and flow resistance, making it an ideal choice for routine maintenance and performance restoration in industrial environments.
Working Principle
The oil-air mixture, driven by system pressure, passes through multiple layers of gradient-density fiber media. Oil mist particles collide, adsorb, and coalesce on the fiber surfaces, gradually forming larger droplets that settle under gravity into the collection zone at the separator bottom. The separated oil is reclaimed via the return line, while the purified compressed air exits through the outlet, enabling continuous gas-liquid physical separation.
Performance Features
Superior Separation Performance: The deep-bed coalescing filtration mechanism reliably reduces oil carryover to extremely low levels, meeting the stringent oil-free air requirements of most industrial applications.
Low Flow Resistance: The optimized media structure ensures a low initial pressure drop, helping to reduce compressor load and save energy consumption.
Extended Service Life: Under normal operating conditions, this element offers a long replacement interval, minimizing maintenance downtime and enhancing continuous production capability.
Durable & Reliable Material: Constructed with high-performance fiber materials that resist heat, oil degradation, and aging, the element maintains structural integrity in sustained humid-oil environments, with no media shedding, ensuring consistent filtration performance over time.
Application Fields
Widely employed in automotive painting, food processing, pharmaceutical manufacturing, precision electronics, chemical, power generation, mining, and general manufacturing sectors that demand high-quality compressed air.
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 02250106-789 |
| Filtration Rating Grade | Sub-micron high-efficiency grade |
| Separation Efficiency | Extremely high, achieving deep purification level |
| Residual Oil Content | Industry-leading low carryover standard |
| Initial Pressure Drop | Low-resistance design for significant energy savings |
| Recommended Replacement ΔP | Within standard industrial recommended range |
| Temperature Tolerance | Suitable for standard compressor operating temperatures |
| Filter Media | High-performance composite fiberglass |
| Compatible Medium | Compressed air / lubricating oil mixture |
