Replace Oil Separator for Atlas
P/N: 1614 9054 00/2906 0564 00
Brand: MENGMA
Filter Type: Wound Type
Quality Control: Internal
Available for sale: National
Use: Oil removal of impurities
Material: Glass Fiber, Stainless Steel, Filter Paper
Model: Complete
Product Advantages
1. Numerous filter material layer,orderly corrugation
2. Strong inner frame
3. High filtration precision
4. Big environmental carrying capacity
5. Fast filtration speed
6. Reduce the bearing wear
7. Prolong the service life of the filter
Air compressor Filter 1614 9054 00/2906 0564 00 Manufacturer Sales
Follow the steps below to properly replace the oil-air separator
1. Turn off the air compressor, close the air pressure outlet, and open the drain valve to confirm that there is no pressure in the system.
2. Disconnect the pipeline above the oil and gas tank, and at the same time remove the pipeline from the outlet of the pressure maintaining valve to the cooler.
3. Remove the oil return line.
4. Remove the fixing bolts on the upper cover of the oil and gas tank, and remove the upper cover of the gas tank.
5. Remove the oil and gas separator and replace it with a new one
6. Install in the reverse order of removal
