1630390494 Coalescing Oil Mist Separator Element for Vacuum Pump & Compressed Air Filtration
Product Description
This coalescing separator element, identified as model 1630390494, is precision-engineered to effectively remove oil aerosols, condensate, and sub-micron particulates from compressed air streams and vacuum pump exhaust systems. The element utilizes advanced multi-layered borosilicate microfiber media, delivering outstanding coalescing performance while maintaining minimal airflow resistance. This ensures that downstream pneumatic equipment, valves, and sensitive instruments remain reliably protected from oil contamination.
The 1630390494 element features a rugged stainless-steel anti-crush inner core and precision-machined aluminum end caps, providing excellent structural durability under pulsating pressure conditions commonly encountered in rotary vane vacuum pumps and screw-type compressors. Its optimized pleated geometry substantially increases the effective filtration surface area, contributing to extended service intervals even in demanding environments with elevated temperatures or fluctuating humidity levels.
Every unit of model 1630390494 undergoes stringent quality control procedures, including 100% leak integrity testing and media performance verification. An integrated rapid-drainage layer promotes efficient shedding of coalesced fluids, effectively preventing oil re-entrainment and ensuring consistent outlet air purity throughout the entire operational lifespan.
Technical Parameters
| Parameter | Specification |
|---|---|
| Model Number | 1630390494 |
| Filtration Rating | High-precision coalescing grade (sub-micron range) |
| Residual Oil Content | Ultra-low oil carryover after filtration |
| Pressure Drop Characteristics | Low initial resistance; gradually increases with contaminant loading |
| Maximum Pressure Tolerance | Suitable for high-pressure industrial systems |
| Operating Temperature Range | Broad range accommodating diverse climatic conditions |
| Flow Capacity | Capable of handling high-volume air/gas flow |
| Core Material | Corrosion-resistant metal |
| End Cap Material | Durable aluminum alloy |
| Seal Material | Oil-compatible elastomer for bypass-free sealing |
Key Features & Benefits
Advanced coalescing media – combines inertial impaction, direct interception, and diffusion mechanisms for thorough aerosol removal.
High contaminant-holding capacity – reduces replacement frequency and lowers total maintenance costs.
Thermally stable construction – resists media degradation even in high-temperature operations.
Bypass-proof sealing system – guarantees full airflow passes through the active filtration layer.
Corrosion-resistant internal components – prolongs element life in humid or chemically aggressive atmospheres.
User-friendly installation – standard dimensional configuration fits most common housing designs.
Typical Applications
Oil-sealed rotary vane vacuum pumps
Oil-injected screw compressors
Industrial air preparation units
Pneumatic material conveying systems
Packaging machinery air supply lines
General manufacturing facility compressed air networks
Installation Guidance
Clean the housing interior thoroughly prior to installation.
Observe the airflow direction indicator to ensure correct orientation.
Secure the retaining nut or tie-rod to the recommended torque specification.
Document the installation date and baseline pressure differential for future reference.
Maintenance Recommendation
Monitor differential pressure regularly; schedule replacement when readings approach the maximum recommended threshold.
For vacuum pump systems, consider replacing this element in conjunction with scheduled oil changes.
Maintain adequate spare stock to minimize unplanned downtime.
Packaging & Logistics
Individually sealed in anti-static moisture-barrier bags with desiccant.
Packed in heavy-duty export-grade cartons with internal foam cushioning.
Custom packaging solutions available on request.
