Air Compressor Oil Filter Element 04.04.3.0001 – High Efficiency Screw Compressor Lubrication Filtration Solution
Product Introduction
The 04.04.3.0001 oil filter cartridge serves as a critical protective component within rotary screw air compressor lubrication circuits. Its primary function is to maintain oil cleanliness by continuously removing suspended particulates, sludge, and chemical degradation residues from the circulating lubricant. By preserving oil quality, this filter effectively reduces mechanical wear, minimizes unplanned downtime, and supports sustained compressor performance across extended operational cycles.
Designed with a focus on durability and consistent filtration efficiency, this cartridge is suitable for a wide range of industrial compression applications.
Performance Advantages
| Advantage | Operational Benefit |
|---|---|
| Superior particle capture | Maintains oil purity, reducing frictional wear on rotating elements |
| Optimized flow dynamics | Low flow resistance promotes energy-efficient compressor operation |
| Rugged internal support | Maintains shape integrity under fluctuating system pressures |
| Reliable interface seal | Precludes oil seepage and ensures stable system pressure retention |
| Thermal stability | Delivers consistent performance across varying ambient and operating temperatures |
| Integrated relief mechanism | Safeguards the compressor by preserving oil circulation during filter clogging conditions |
Specification Summary
| Attribute | Detail |
|---|---|
| Product Identifier | 04.04.3.0001 |
| Functional Category | Full-flow lubricant filtration cartridge |
| Filtration Capability | High-efficiency classification |
| Flow Resistance | Engineered for minimal pressure drop |
| Thermal Operating Range | Suitable for diverse temperature conditions |
| Flow Orientation | Outside to inside |
| Fluid Compatibility | Compatible with standard mineral oils, synthetic lubricants, and hydrocarbon-based fluids |
| Expected Service Life | Long operational duration (varies with actual usage conditions) |
| Construction Profile | Cylindrical body with integrated housing / Single-use design |
Construction & Functional Details
Filtration Layer Characteristics
The filtration medium is engineered with a tightly controlled fiber matrix that provides high particle retention capacity while maintaining adequate permeability. This balanced design ensures that the oil passes through with minimal resistance, while contaminants are effectively retained within the filtration layer. The medium maintains its physical properties and filtration performance throughout its service life, even under continuous oil circulation conditions.
Central Support Framework
A robust central support structure runs through the interior of the cartridge. Perforations distributed along its surface enable unrestricted oil passage after the filtration stage. This support framework provides essential reinforcement against external pressure forces, preventing deformation or collapse of the filtration layer that could compromise performance. The framework is securely attached to the end closures at both extremities.
Pressure Relief Bypass Configuration
An integrated bypass mechanism is situated at one end of the cartridge assembly. This mechanism incorporates a spring-loaded closing element that remains seated during normal pressure differential conditions. Should the differential pressure rise beyond the predetermined threshold-indicating significant filter restriction-the closing element unseats, allowing oil to pass through an alternative route. This protective feature ensures continuous lubrication supply to critical compressor components, preventing damage from oil starvation.
Sealing Arrangement
A precisely engineered seal ring is incorporated at the connection interface of the cartridge. The seal design ensures positive contact with the mating surface of the filter housing, forming an effective barrier against oil escape. The seal geometry has been optimized to provide reliable containment without necessitating excessive tightening force during installation.
End Closure Attachment
The end closures at both extremes of the cartridge are permanently joined to the filtration medium. This attachment is designed to resist the mechanical stresses imposed by circulating oil flow, ensuring that the cartridge remains fully intact throughout its entire service interval.
Why Partner with XINXIANG MENGMA FILTER?
Industry insight – Extensive hands-on expertise in filtration product development and manufacturing processes
Rigorous quality oversight – Systematic inspection protocols applied throughout production runs
Customization flexibility – Capability to manufacture based on client-provided drawings or reference samples
Supply reliability – Common models held in ready stock; production initiated promptly upon order placement
Export-grade packaging – Sturdy carton solutions designed to protect products during international shipping
Primary Application Areas
Rotary screw type air compression equipment
Industrial plant compressed air generation systems
Lubricating oil purification and conditioning circuits
Full-flow filtration configurations in hydraulic and lube systems
