Air Compressor Oil Filter 2901016612 for Screw Compressor Lubrication
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | 2901016612 |
| Product Type | Air Compressor Oil Filter Element / Oil Filter |
| Filtration Precision | High-Precision Filtration |
| Filtration Efficiency | High-Efficiency Suspended Contaminant Interception |
| Seal Material | Oil & Heat Resistant Nitrile Rubber |
| Installation Type | Direct Replacement |
| Application | Screw Air Compressors |
| MOQ | Sample Acceptable |
| Packaging | PP Bag + Inner Box + Export Carton / Wooden Case (Customizable) |
| Loading Port | Shanghai / Tianjin / Qingdao / Others |
| Lead Time | To Be Arranged Upon Order Confirmation |
Product Details
Product Overview
The oil filter element 2901016612 is specifically engineered for the lubricating oil circulation system of screw air compressors, tasked with continuously removing suspended contaminants from the oil. During compressor operation, lubricating oil gradually accumulates thermal cracking by-products, fine metallic debris from friction pairs, and airborne dust particles that have entered through the intake system. If not effectively intercepted, these impurities accelerate bearing wear, damage rotor coatings, and shorten the interval between compressor overhauls. This filter element is specifically designed to address these contamination challenges.
Structure and Working Principle
Under system pressure, oil flows from the outer surface inward through the filtration layers and into the central collection tube, where contaminants are trapped within the depth of the filtration layers - this depth-loading mode ensures that multiple layers participate in particle capture, delaying surface blinding.
A bypass valve is integrated into the filter base. When the retained contaminant load raises the pressure differential to the preset range, the bypass valve mechanically opens, allowing oil to travel around the filter media and directly reach the compressor lubrication points. The core value of this design is that even when the element has reached its replacement threshold, the compressor continues to receive adequate oil flow, preventing bearing seizure or rotor locking caused by oil supply interruption.
Product Features
Pleated Filtration Structure: The internal filtration element adopts a pleated design, providing a larger effective filtration area within a compact space and ensuring smooth oil flow.
Integrated Bypass Valve: A bypass valve mechanism is located at the base. When the pressure differential rises due to retained contaminants on the filtration element, the valve opens automatically to ensure continuous oil flow to the compressor lubrication points, preventing oil supply interruption.
Center Tube Support Structure: The internal center tube provides radial support to the filtration layers, preventing inward collapse under pressure while serving as the collection channel for filtered oil.
End Cap Sealing Fit: The end cap is bonded to the filtration layers, forming a reliable sealing interface with the filter housing upon installation to prevent unfiltered oil bypass leakage.
Metal Housing Protection: The external metal housing structure provides mechanical protection to the internal filtration element, withstanding vibration and pressure fluctuations during compressor operation.
Quality Control
Production leverages the mature filtration industry infrastructure in Xinxiang, with a complete flow covering filtration layer slitting, pleating and forming, end cap bonding, and final air-tightness testing. Permeability and crush resistance of the filtration layers are verified through sample testing for each production batch. External dimensions of finished elements are 100% inspected using go/no-go gauges to ensure consistent mounting interface accuracy on every unit shipped. Process data is recorded and kept traceable to support customer expectations for parts uniformity and reliability.
