Precision Compressed Air Filter Element for 1629315043 3V Filter Housing
Product Overview
This precision filter element is designed to fit the 1629315043 3V filter housing, serving as the final-stage filtration unit in compressed air systems. Built with high-efficiency glass fiber coalescing media and multi-layer depth filtration structure, it effectively removes residual oil aerosols, liquid water, and fine solid particles, delivering clean and dry air for pneumatic tools, precision instruments, spraying equipment, and other downstream applications.
Key Advantages
Consistent Filtration Performance – Maintains low outlet oil content under rated operating conditions, meeting standard industrial air quality requirements.
Robust Construction – Inner and outer cores are made of corrosion-resistant materials with good collapse resistance, suitable for variable system pressures.
Energy-Efficient Low ΔP – Optimized pleat geometry reduces flow resistance, helping to lower compressor energy consumption.
Reasonable Service Life – Adequate dust-holding capacity, especially when combined with proper prefiltration, extends maintenance intervals and reduces downtime.
Operating Conditions
Suitable for compressed air systems with trace lubricating oil vapor
Compatible with general ambient temperatures and standard working pressure ranges (seal material optional)
Flow rating matches the nominal capacity of 1629315043 3V housing
Product Features
| Item | Description |
|---|---|
| Compatible Model | 1629315043 3V |
| Flow Direction | Outside-in / Inside-out (depending on housing design) |
| Filter Media | Borosilicate glass fiber + synthetic fiber protective layer |
| End Cap Design | Double end cap with anti-misalignment feature |
| Seal Material | Standard NBR / Optional FKM (high-temperature resistant) |
| Dimensions | Manufactured to precisely match housing specifications |
Quality Statement
All elements are produced under strict process control. Each batch undergoes visual inspection and air-flow integrity testing to ensure reliable sealing and no bypass leakage after installation.
Packaging & Shipping
Each filter element is individually sealed in moisture-proof packaging, then placed in a carton or custom wooden case.
Multiple shipping methods available: courier, freight, and sea freight; export documentation support is provided.
Company Information
XINXIANG MENGMA FILTER CO.,LTD.
With years of manufacturing experience in the filtration industry, we welcome custom orders based on drawings or samples.
Contact: Joy
Tel / WhatsApp: +86 150 9033 8589
Email: joy@mmfilter.com
Address: Xinxiang, Henan, China
