Air Compressor Precision Filter Element 6104402 | Efficient Oil-Water & Dust Removal | For Compressed Air Aftertreatment Systems
Product Specifications Overview
| Item | Description |
|---|---|
| Model | 6104402 |
| Suitable Medium | Compressed air, nitrogen, inert gas |
| Flow Direction | Inside → out / Outside → in (housing dependent) |
| Filter Media | Multi-layer composite fiber |
| Support Structure | Stainless steel inner & outer mesh |
| End Cap Material | High-strength industrial plastic |
| Seal Ring | Oil & temperature resistant rubber |
| Temp. Range | Wide temperature suitability |
| Pressure Rating | Suitable for standard industrial compressor systems |
| Replacement Cycle | Based on actual working condition & ΔP indicator |
Product Details - Multi‑Dimensional Description
1. Filtration Performance & Purification
This filter element uses a depth‑gradient filtration structure to effectively capture liquid water, oil mist, fine dust, and rust particles from compressed air. The multi‑layer fiber media provides both surface interception and deep adsorption, ensuring clean and dry air for downstream equipment and reducing maintenance frequency for dryers, refrigerated air dryers, and pneumatic tools.
2. Structural Strength & Durability
Both inner and outer layers are reinforced with perforated metal mesh, offering stable resistance against pressure and deformation. The bonding between end caps and media uses high‑strength adhesives. Even under frequent flow fluctuations or system start‑stop impacts, the element maintains its shape without bypassing, collapsing, or end cap detachment.
3. Low Flow Resistance Design
With optimized pleat height and spacing, this element maintains low airflow resistance at rated flow conditions. This reduces compressor backpressure and system energy consumption, making it ideal for continuous industrial production lines. Longer service life also lowers manual replacement frequency and downtime.
4. Reliable Sealing & Leak Prevention
Precision‑molded seal grooves on both end caps, combined with high‑quality oil‑resistant NBR rubber seals, guarantee reliable sealing between the element and housing. This prevents untreated air from bypassing the filter, ensuring every cubic meter of compressed air is effectively filtered.
5. Typical Applications & Industries
Automotive paint & baking booths
Food & beverage filling lines
Pharmaceutical & fermentation processes
Electronics assembly & blow‑off
Textile, chemical fiber & precision manufacturing
Pneumatic control systems & instrument air
6. Quality Control & Factory Standard
Each filter element undergoes internal integrity and structural visual inspection before packaging. Pleats are uniform and damage‑free; end caps have no burrs or ungluing. All products follow a unified manufacturing process to ensure batch‑to‑batch consistency.
